LM2936MPX-3.3/NOPB
具有反向电压保护功能的 50mA、60V、低 IQ、低压降稳压器 4-SOT-223 -40 to 125
PMIC - 稳压器 - 线性 正 固定 1 输出 50mA SOT-223-4
得捷:
IC REG LINEAR 3.3V 50MA SOT223-4
立创商城:
LM2936MPX-3.3/NOPB
德州仪器TI:
50-mA, 60-V, low-IQ, low-dropout voltage regulator with reverse voltage protection
贸泽:
LDO Voltage Regulators Ultra-Low Quiescent Current LDO Voltage Regulator 4-SOT-223 -40 to 125
艾睿:
Control the voltage level of your circuit with this LDO LM2936MPX-3.3/NOPB linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.05@100uA|0.2@50mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.05 A. It only needs a voltage of at least 4 V while not exceeding 40 V to effectively power your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. By operating at a load regulation of 30mV and line regulation of 30mV you can provide a constant voltage at your output. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Its polarity is positive. The maximum dropout voltage is 0.1@100uA|0.4@50mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
安富利:
LDO Regulator Pos 3.3V 0.05A 4-Pin3+Tab SOT-223 T/R
Chip1Stop:
LDO Regulator Pos 3.3V 0.05A 4-Pin3+Tab SOT-223 T/R
Verical:
LDO Regulator Pos 3.3V 0.05A Automotive 4-Pin3+Tab SOT-223 T/R
DeviceMart:
IC REG LDO 3.3V 50MA SOT223-4
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 50mA SOT-223-4
