LM2936BM-5.0
TI(德州仪器)
主动器件
TEXAS INSTRUMENTS LM2936BM-5.0. 固定电压稳压器, LDO, 5.5V至40V, 200mV压差, 5V输出, 50mA输出, SOIC-8
The is a 5V fixed output ultra-low quiescent current Linear Regulator features low-dropout LDO voltage and low current in the standby mode. With less than 15µA quiescent current at a 100µA load, the device is ideally suited for automotive and other battery operated systems. The device retains all of the features that are common to low-dropout LDO regulators including a low-dropout LDO PNP pass device, short circuit protection, reverse battery protection and thermal shutdown. The device has a 40V maximum operating voltage limit and ±3% output voltage tolerance over the entire output current, input voltage and temperature range.
- .
- ±2% Initial output tolerance
- .
- ±3% Output tolerance over line, load and temperature
- .
- Dropout voltage typically 200mV at IOUT = 50mA
- .
- -24V Input voltage protection
- .
- -50V Input transient protection
- .
- Shutdown pin
