LP3871EMP-3.3/NOPB
TEXAS INSTRUMENTS LP3871EMP-3.3/NOPB 固定电压稳压器, LDO, 2.5V至7V, 240mV压差, 3.3V输出, 800mA输出, SOT-223-5
LDO（低压降）线性稳压器，600mA 至 800mA，Texas Instruments
### LDO（低压降）线性稳压器，Texas Instruments
低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
立创商城:
正 Vin=7V Vout=3.3V 800mA 73dB@120Hz
德州仪器TI:
800-mA, 7-V, low-dropout voltage regulator with power good & enable
得捷:
IC REG LIN 3.3V 800MA SOT223-5
欧时:
### LDO（低压降）线性电压调节器，600mA 至 800mA，Texas Instruments### LDO（低压降）线性电压调节器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
e络盟:
固定电压稳压器, LDO, 2.5V至7V, 240mV压差, 3.3V输出, 800mA输出, SOT-223-5
艾睿:
Don&s;t let unpredictable voltage levels ruin your circuit! Use this LDO LP3871EMP-3.3/NOPB linear regulator from Texas Instruments to control your voltage levels! Its typical dropout voltage at current is 0.024@80mA|0.24@800mA V. It has an overall accuracy of ±1.5 %. This voltage regulation device&s;s single output can produce a current up to 0.8 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.5 V that does not exceed 7 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. At a load regulation of 0.04%Typ and line regulation of 0.02%Typ a constant current can be produced at the output of your circuit. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. The maximum dropout voltage is 0.035@80mA|0.3@800mA V. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
安富利:
LDO Regulator Pos 3.3V 0.8A 5-Pin4+Tab SOT-223 T/R
Verical:
LDO Regulator Pos 3.3V 0.8A 5-Pin4+Tab SOT-223 T/R
Newark:
# TEXAS INSTRUMENTS LP3871EMP-3.3/NOPB Fixed LDO Voltage Regulator, 2.5V to 7V, 240mV Dropout, 3.3Vout, 800mAout, SOT-223-5
DeviceMart:
IC REG LDO 3.3V .8A SOT223-5
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 800mA SOT-223-5
