LM2936QMM-3.0/NOPB

具有反向电压保护功能的汽车类 50mA、电池供电运行 60V、低压降稳压器 8-VSSOP -40 to 125

PMIC - 稳压器 - 线性 输出 50mA 8-VSSOP

立创商城:
LM2936QMM-3.0/NOPB

德州仪器TI:
Automotive 50-mA, off-battery 60-V, low-dropout voltage regulator with reverse voltage protection

得捷:
IC REG LINEAR 3V 50MA 8VSSOP

贸泽:
LDO Voltage Regulators Ultra-Low Quiescent Current LDO Voltage Regulator 8-VSSOP -40 to 125

艾睿:
Use the LDO LM2936QMM-3.0/NOPB linear regulator from Texas Instruments to maintain a constant output voltage. Its typical dropout voltage at current is 0.05@100uA|0.2@50mA V. It has an overall accuracy of ±3 %. This voltage regulation device&s;s single output can produce a current up to 0.05 A. Use this part at voltages lower than 40 V. With a fixed output that has a voltage of 3 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 30mV and line regulation of 30mV. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive. The maximum dropout voltage is 0.1@100uA|0.4@50mA V.

Chip1Stop:
LDO Regulator Pos 3V 0.05A 8-Pin VSSOP T/R
