LP2986AIM-3.0/NOPB

具有可调节或固定电压配置的 200mA、16V 低压降稳压器 8-SOIC -40 to 125

The LP2986 is a 200-mA high-precision LDO regulator with a wide input voltage supply. The device has two output voltage modes: a fixed-precision output mode and an adjustable output voltage via an external resistive divider.

Using an optimized Vertically Integrated PNP VIP process, the LP2986 delivers superior performance:

得捷:
IC REG LINEAR 3V 200MA 8SOIC

立创商城:
LP2986AIM-3.0/NOPB

德州仪器TI:
200-mA, 16-V, low-dropout voltage regulator with adjustable or fixed voltage configuration

艾睿:
Make a theoretical system actual by providing stable voltages with this LDO LP2986AIM-3.0/NOPB linear regulator from Texas Instruments. It has an overall accuracy of ±0.5 %. Its typical dropout voltage at current is 0.001@0.1mA|0.09@75mA|0.18@200mA V. This voltage regulation device&s;s single output can produce a current up to 0.2 A. By only needing an input voltage of 2.1 V with a maximum of 16 V, this is the best way to control the power in your circuit. With a fixed output that has a voltage of 3 V, this is power management at its best. At a line regulation of 0.014%/V your circuit is capable of maintaining a constant voltage level at your output. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its polarity is positive. The maximum dropout voltage is 0.002@0.1mA|0.12@75mA|0.23@200mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.

安富利:
LDO Regulator Pos 3V 0.2A 8-Pin SOIC N Rail

Verical:
LDO Regulator Pos 3V 0.2A 8-Pin SOIC Tube

Newark:
# TEXAS INSTRUMENTS  LP2986AIM-3.0/NOPB  Fixed LDO Voltage Regulator, 2.1V to 16V In, 180mV Dropout, 3V/200mA Out, SOIC-8

DeviceMart:
IC REG LDO 3V .2A 8-SOIC

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3V 200mA 8-SOIC
