LM2936BMX-3.3/NOPB
具有反向电压保护功能的 50mA、60V、低 IQ、低压降稳压器 8-SOIC -40 to 125
PMIC - 稳压器 - 线性 正 固定 输出 50mA 8-SOIC
得捷:
IC REG LINEAR 3.3V 50MA 8SOIC
立创商城:
LM2936BMX-3.3/NOPB
德州仪器TI:
50-mA, 60-V, low-IQ, low-dropout voltage regulator with reverse voltage protection
艾睿:
Control the voltage level of your circuit with this LDO LM2936BMX-3.3/NOPB linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.05@100uA|0.2@50mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.05 A. Using the part will provide the power your application needs by requiring a voltage only of 4 V and not exceeding a voltage of 40 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. A load regulation of 30mV and line regulation of 30mV is necessary for providing a constant voltage level at your output. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. The maximum dropout voltage is 0.1@100uA|0.4@50mA V. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.
安富利:
LDO Regulator Pos 3.3V 0.05A 8-Pin SOIC N T/R
Chip1Stop:
LDO Regulator Pos 3.3V 0.05A 8-Pin SOIC T/R
Verical:
LDO Regulator Pos 3.3V 0.05A Automotive 8-Pin SOIC T/R
DeviceMart:
IC REG LDO 3.3V 50MA 8-SOIC
