LM3480IM3X-3.3/NOPB
TEXAS INSTRUMENTS LM3480IM3X-3.3/NOPB 芯片, 稳压器, LDO, 固定, 3.3V, 100mA, SOT-23-3
PMIC - 稳压器 - 线性 正 固定 输出 100mA SOT-23-3
立创商城:
正 Vin=30V Vout=3.3V 100mA
得捷:
IC REG LINEAR 3.3V 100MA SOT23-3
欧时:
LM3480IM3X-3.3/NOPB, LDORegulatorPos
德州仪器TI:
100-mA, 30-V, low-dropout voltage regulator
贸泽:
低压差稳压器
e络盟:
固定LDO稳压器, 4 V至30 V, 900 mV压差, 3.3 V/100 mA输出, SOT-23-3
艾睿:
This LDO LM3480IM3X-3.3/NOPB linear regulator from Texas Instruments acts like a variable resistor to maintain a steady voltage level. It has an overall accuracy of ±5 %. This device has a maximum power dissipation of 250 mW. Its typical dropout voltage at current is 0.7@10mA|0.9@100mA V. This voltage regulation device&s;s single output can produce a current up to 0.1Min A. By working with a maximum input voltage of 30 V, this is the best way to control the power in your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 20mVTyp and line regulation of 10mVTyp. Its maximum power dissipation is 250 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. Its polarity is positive. The maximum dropout voltage is 0.9@10mA|1.1@100mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
安富利:
LDO Regulator Pos 3.3V 0.1A 3-Pin SOT-23 T/R
Chip1Stop:
LDO Regulator Pos 3.3V 0.1A 3-Pin SOT-23 T/R
Verical:
LDO Regulator Pos 3.3V 0.1A 3-Pin SOT-23 T/R
Newark:
# TEXAS INSTRUMENTS LM3480IM3X-3.3/NOPB Fixed LDO Voltage Regulator, 0V to 30V In, 1.2V Dropout, 3.3V/100mA Out, SOT-23-3
DeviceMart:
IC REG LDO 3.3V .1A SOT23-3
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 100mA SOT-23-3
