LMH6622MA
TI(德州仪器)
主动器件
TEXAS INSTRUMENTS LMH6622MA 运算放大器, 双路, 160 MHz, 2个放大器, 85 V/µs, ± 2.25V 至 ± 6V, SOIC, 8 引脚
The is a dual wideband high speed voltage feedback Operational Amplifier specifically optimized for low noise applications. A voltage noise specification of 1.6nV/√Hz, a current noise specification 1.5pA/√Hz, a bandwidth of 160MHz and a harmonic distortion specification that exceeds 90dBc combine to make the LMH6622 an ideal choice for the receive channel amplifier in ADSL, VDSL or other xDSL designs. The LMH6622 is stable for AV>=2 or AV<=-1. The fabrication of the LMH6622 on "s advanced VIP10 process enables excellent 160MHz bandwidth at a current consumption of only 4.3mA/amplifier.
- .
- -4.75 to +5.7V Input common-mode voltage
- .
- ±4.6V Output voltage swing RL=100R
- .
- 90mA Linear output current
- .
- 100dB Typical CMRR
- .
- 2.5µV/°C Typical offset drift
- .
- Green product and no Sb/Br
