LM224AN
TI(德州仪器)
主动器件
TEXAS INSTRUMENTS LM224AN 运算放大器, 1.2 MHz, 4个放大器, 0.5 V/µs, 3V 至 30V, DIP, 14 引脚
The is a 4 independent high-gain frequency-compensated Operational Amplifier designed specifically to operate from a single supply or split supply over a wide range of voltages.
- .
- Internal frequency compensation
- .
- Common-mode input voltage range includes ground, allowing direct sensing near ground
- .
- Low input bias and offset parameters
- .
- 2kV ESD Protection
- .
- 0.8mA Typical low supply-current drain independent of supply voltage
- .
- 2mV Typical input offset voltage
- .
- 2nA Typical input offset current
- .
- 15nA Typical input bias current
- .
- 32V Differential input voltage range equal to maximum-rated supply voltage
- .
- 100V/mV Typical open-loop differential voltage amplification
- .
- Green product and no Sb/Br
