ADC081S021CIMF
TEXAS INSTRUMENTS ADC081S021CIMF 模数转换器, 8 bit, 200 kSPS, 单, 2.7 V, 5.25 V, SOT-23
The is a 1-channel 8-bit CMOS Analog-to-digital Converter ADC with a high-speed serial interface. Unlike the conventional practice of specifying performance at a single sample rate only, the ADC081S021 is fully specified over a sample rate range of 50 to 200 kSPS. The converter is based upon successive-approximation register architecture with an internal track-and-hold circuit. The output serial data is straight binary and is compatible with several standards such as SPI, QSPI, MICROWIRE and many common DSP serial interfaces. It operates with a single supply that can range from 2.7 to 5.25V. The power-down feature reduces the power consumption to as low as 2.6µW using a 5.25V supply.
- .
- Specified over a range of sample rates
- .
- Variable power management
- .
- SPI™/QSPI™/MICROWIRE/DSP compatible
- .
- Green product and no Sb/Br
