AD712JR-REEL7

双路精密，低成本，高速BiFET运算放大器 Dual Precision, Low Cost, High Speed BiFET Op Amp

J-FET Amplifier 2 Circuit 8-SOIC

得捷:
IC OPAMP JFET 2 CIRCUIT 8SOIC

贸泽:
精密放大器 PREC HIGH Spd DUAL BIFET

艾睿:
OP Amp Dual GP

安富利:
The AD712 is a high speed, precision, monolithic operational amplifier offering high performance at very modest prices. Its very low offset voltage and offset voltage drift are the results of advanced laser wafer trimming technology. These performance benefits allow the user to easily upgrade existing designs that use older precision BiFETs and, in many cases, bipolar op amps. The superior ac and dc performance of this op amp makes it suitable for active filter applications. With a slew rate of 16 V/μs and a settling time of 1 μs to ±0.01%, the AD712 is ideal as a buffer for 12-bit digital-to-analog converters DACs and analogto-digital converters ADCs and as a high speed integrator. The settling time is unmatched by any similar IC amplifier. The combination of excellent noise performance and low input current also make the AD712 useful for photo diode preamps. Common-mode rejection of 88 dB and open-loop gain of 400 V/mV ensure 12-bit performance even in high speed unity-gain buffer circuits. The AD712 is pinned out in a standard op amp configuration and is available in seven performance grades. The AD712J and AD712K are rated over the commercial temperature range of 0°C to 70°C. The AD712A is rated over the industrial temperature range of −40°C to +85°C. The AD712S is rated over the military temperature range of −55°C to +125°C and is available processed to MIL-STD-883B, Rev. C. Extended reliability PLUS screening is available, specified over the commercial and industrial temperature ranges. PLUS screening includes 168-hour burn-in, in addition to other environmental and physical tests.

Chip1Stop:
OP Amp Dual GP ±18V 8-Pin SOIC N T/R

Verical:
OP Amp Dual GP ±18V 8-Pin SOIC N T/R

罗切斯特:
OP Amp Dual GP ±18V 8-Pin SOIC N T/R

Win Source:
IC OPAMP JFET 4MHZ 8SOIC
