ADS8361IRHBT
双通道， 500KSPS ， 16位，2个2通道，同步采样模拟数字转换器 Dual, 500kSPS, 16-Bit, 2 2 Channel, Simultaneous Sampling ANALOG-TO-DIGITAL CONVERTER
DESCRIPON
The ADS8361 is a dual, 16-bit, 500kSPS, Analog-to-Digital A/D converter with four fully differential input channels grouped into two pairs for high-speed, simultaneous signal acquisition. Inputs to the sample-and-hold amplifiers are fully differential and are maintained differentially to the input of the A/D converter. This provides excellent common-mode rejection of 80dB at 50kHz, which is important in high-noise environments.
FEATURES
●2 SIMULTANEOUS 16-BIT DACs
●4 FULLY DIFFERENTIAL INPUT CHANNELS
●2μs THROUGHPUT PER CHANNEL
●4μs TOTAL THROUGHPUT FOR FOUR CHANNELS
●LOW POWER: 150mW
●INTERNAL REFERENCE
●FLEXIBLE SERIAL INTERFACE
●16-BIT UPGRADE TO THE 12-BIT ADS7861
●PIN COMPATIBLE WITH THE ADS7861
●OPERATING TEMPERATURE RANGE: –40°C to +125°C
APPLICATIONS
●MOTOR CONTROL
●MULTI-AXIS POSITIONING SYSTEMS
●3-PHASE POWER CONTROL
