AM26C32CNE4

四路差动线路接收器 QUADRUPLE DIFFERENTIAL LINE RECEIVERS

description/ordering information

The AM26C32 is a quadruple differential line receiver for balanced or unbalanced digital data transmission. The enable function is common to all four receivers and offers a choice of active-high or active-low input. The 3-state outputs permit connection directly to a bus-organized system. Fail-safe design specifies that if the inputs are open, the outputs always are high.

Meets or Exceeds the Requirements of ANSI A/EIA-422-B, TIA/EIA-423-B, and ITU Recommendation V.10 and V.11

Low Power, ICC= 10 mA Typ

±7-V Common-Mode Range With ±200-mV Sensitivity

Input Hysteresis. . . 60 mV Typ

tpd= 17 ns Typ

Operates From a Single 5-V Supply

3-State Outputs

Input Fail-Safe Circuitry

Improved Replacements for AM26LS32

Available in Q-Temp Automotive

  − High Reliability Automotive Applications

  − Configuration Control/Print Support

  − Qualification to Automotive Standards
