SL-112-G-10、SL-112-T-10、SL-112-TT-10对比区别
型号 SL-112-G-10 SL-112-T-10 SL-112-TT-10
描述 SAMTEC SL-112G-10 Board-To-Board Connector, 2.54mm, 12Contacts, Receptacle, SL Series, Through Hole, 1RowsLow Profile 2.54mm Screw Machined Socket Strips - SL SeriesSL series board to board machined through hole single row socket strips with a 2.54mm pitch and a low profile design. The body of these SL series board-to-board PCB socket strips is made from black glass filled polyester and the contacts are made from phosphor bronze with a 0.76μm gold plating and tin shell. The temperature range at which these board to board machined stacking terminals can be used is -55 to +125°C. Part numbers SL-XXX-X-10 have hollow leg contacts with a 3.10mm pin shoulder height. Part numbers SL-XXX-X-12 are micro sockets which have hollow leg contacts with a 2.41mm pin shoulder height.### 注These SL series board-to-board machined socket strips mate with the following: BBL series header terminal strips: see stock number 766-6367 typically. BBS series header terminal strips: see stock number 766-6442 typically. TS series header terminal strips - see stock number 765-6414 typically.### 2.54 mm 板对板和线对板 - SamtecSAMTEC SL-112-TT-10 Board-To-Board Connector, 2.54mm, 12Contacts, Receptacle, SL Series, Through Hole, 1Rows
数据手册 ---
制造商 Samtec (申泰电子) Samtec (申泰电子) Samtec (申泰电子)
分类 板对板连接器插座板对板连接器
安装方式 Through Hole Through Hole Through Hole
封装 - - -
引脚间距 2.54 mm 2.54 mm 2.54 mm
触点数 12 12 12
极性 Female Female Female
触点电镀 Gold Gold Tin
排数 1 1 1
针脚数 12 12 12
额定电流(Max) 1 A - -
工作温度(Max) 125 ℃ - -
工作温度(Min) -55 ℃ - -
接触电阻(Max) 10 mΩ - -
额定电流 - 1 A -
接触电阻 - 10.0 mΩ -
长度 30.5 mm 30.5 mm 30.5 mm
宽度 2.54 mm 2.54 mm 2.54 mm
高度 3.1 mm 1.27 mm 1.27 mm
封装 - - -
引脚间距 2.54 mm 2.54 mm 2.54 mm
外壳颜色 Black Black Black
颜色 Black Black Black
触点材质 Beryllium Copper Beryllium Copper Beryllium Copper
工作温度 -55℃ ~ 125℃ -55℃ ~ 125℃ -55℃ ~ 105℃
外壳材质 Plastic Plastic Plastic
产品生命周期 Discontinued at Digi-Key Discontinued at Digi-Key Discontinued at Digi-Key
包装方式 Tube Tube Tube
RoHS标准 RoHS Compliant RoHS Compliant RoHS Compliant
含铅标准 Lead Free Lead Free Lead Free
REACH SVHC标准 No SVHC No SVHC No SVHC
REACH SVHC版本 2015/06/15 2015/06/15 2015/06/15
ECCN代码 - EAR99 -
