八路缓冲器并用3态输出线路驱动器 OCTAL BUFFERS AND LINE DRIVERS WITH 3-STATE OUTPUTS
description
These octal buffers and line drivers are designed to have the performance of the popular ’HC240 series devices and to offer a pinout with inputs and outputs on opposite sides of the package. This arrangement greatly facilitates printed circuit board layout.
Operating Voltage Range of 4.5 V to 5.5 V
High-Current 3-State Outputs Interface Directly With System Bus or Can Drive Up To 15 LSTTL Loads
Low Power Consumption, 80-µA Max ICC
Typical tpd = 12 ns
±6-mA Output Drive at 5 V
Low Input Current of 1 µA Max
Inputs Are TTL-Voltage Compatible
Data Flow-Through Pinout All Inputs on Opposite Side From Outputs
