JF15CP2C

NKK SWITCHES  JF15CP2C  轻触开关, 不发光, 3 N, 24 V, 50 mA, 焊接, JF系列

顶部触动 触摸 SPST-NO 通孔

得捷:
SWITCH TACTILE SPST-NO 0.05A 24V

贸泽:
Tactile Switches SPST RND/RND RED

e络盟:
轻触开关, JF系列, 顶部操作, 通孔安装, 圆形按钮, 300 gf, 24VDC时, 50mA

艾睿:
Apply pressure and turn your circuit on with this ultra-thin JF15CP2C tactile switch from NKK Switches. This device has a maximum current rating of 0.05 A @ 24VDC. It has a SPST configuration. This tactile switch has an operating temperature range of -25 °C to 85 °C. The JF15CP2C tactile switch has a PC pin termination style. This red flush round button actuator is 0 mm long. The maximum DC voltage rating is 24 VDC. This product is 17.7 mm long, 5.08 mm tall and 17.7 mm deep.

Allied Electronics:
Switch, TACTILE, NONIlluminated W/ROUND BLACK HOUSING, 50MA@24VDC, ROUND RED ACTUAT.

Chip1Stop:
Switch Tactile OFF ON SPST Flush Round Button PC Pins 0.05A 24VDC 500000Cycles 3N Thru-Hole

Verical:
Switch Tactile OFF ON SPST Flush Round Button PC Pins 0.05A 24VDC 500000Cycles 3N Thru-Hole

Newark:
# NKK SWITCHES  JF15CP2C  Tactile Switch, Non Illuminated, 24 V, 50 mA, 3 N, Solder, JF Series
