GLFR1608T6R8M-LR

0603 6.8uH ±20% 400mA

6.8µH Shielded Inductor 400mA 350mOhm 0603 1608 Metric

得捷:
FIXED IND 6.8UH 400MA 350 MOHM

艾睿:
This power chip GLFR1608T6R8M-LR surface mount inductor from TDK is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 105 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has an inductance of 6.8u H. This device is made with wirewound technology. Its test frequency is 7.96M Hz. It has a tolerance of 20%. This product is 1.8 mm long, 1 mm tall and 1 mm deep. This SMD inductor has a maximum DC current of 400m A with a maximum resistance of 350mTyp Ohm.

富昌:
GLFR Series 0603 6.8 uH ±20 % Tol. 350 mOhm DCR 400 mA Shielded Power Inductor

Verical:
Inductor Power Chip Shielded Wirewound 6.8uH 20% 7.96MHz 400mA 350mOhm DCR 0603 T/R

Win Source:
6.8μH Shielded Wirewound Inductor 400mA 350 mOhm 0603 1608 Metric
