FAN3229TMX

FAIRCHILD SEMICONDUCTOR  FAN3229TMX  驱动器, MOSFET, 低压侧, 4.5V-18V电源, 3A输出, 19ns延迟, SOIC-8

The is a high-speed low-side Gate Driver for synchronous rectifier circuits. The FAN3229 family of dual 2A gate driver is designed to drive N-channel enhancement-mode MOSFETs in low-side switching applications by providing high peak current pulses during the short switching intervals. The driver is available with TTL input thresholds. Internal circuitry provides an under-voltage lockout function by holding the output low until the supply voltage is within the operating range. In addition, the driver feature matched internal propagation delays between A and B channels for applications requiring dual gate drives with critical timing, such as synchronous rectifiers. This enables connecting two drivers in parallel to effectively double the current capability driving a single MOSFET. The FAN322X driver incorporates MillerDrive™ architecture for the final output stage.

.

Industry-standard pinouts

.

Internal resistors turn driver off if no inputs

.

Double current capability by paralleling channels
