ERZV05D221

ZNR 系列，5mm 直径，Panasonic相对于紧凑的结构而言，具有较大的浪涌电流处理能力 相对于标准变速器而言，提升了 2 浪涌电流处理能力 类型 | 直径 （标称 /最大）mm | 节距 mm | 高度（印刷电路板上） mm ---|---|---|--- ERZV05 | 5 / 7 | 5 ±1 | 10 ERZV07 | 7 / 8.5 | 5 ±1 | 11.5 ERZV10 | 10 / 12.5 | 7.5 ±1 | 15.5 ERZV14 | 14 / 16 | 7.5 ±1 | 19 ERZV20 | 20 / 21.5 | 10 ±1 | 24.5 ### 瞬态电压抑制器 径向金属氧化物变阻器

Var 140VAC/180VDC 800A 220V Radial Bulk

欧时:
Panasonic ZNR 系列 110pF 5A 380V 金属氧化物压敏电阻 ERZV05D221, 7 Dia. x 4.5mm

艾睿:
Never worry about improper resistance being seen by your components with this ERZ-V05D221 MOV from Panasonic, it will change depending on voltages. This part has a pitch of 5 mm. This device&s;s clamping current is 5 A and clamping voltage is 380 V. Its maximum surge current is 800 A. This voltage dependent resistor has an operating temperature of -40 to 85 °C. This product comes packaged in bulk, so the parts will be stored loosely. This product is 10 mm tall and 4.5 mm deep with a diameter of 7 mm. This varistor has a voltage of 220 V. Its capacitance value is 110pF. The maximum AC voltage rating is 140 VAC and the maximum DC voltage rating is 180 VDC.

安富利:
Var 140VAC/180VDC 800A 220V Radial Bulk

Chip1Stop:
Var 140VAC/180VDC 800A 220V Radial Bulk
