ERJ8RQF2R0V
数据手册.pdfPANASONIC ELECTRONIC COMPONENTS ERJ8RQF2R0V 电流感应电阻器, 表面安装, AEC-Q200 ERJ系列, 2 ohm, 250 mW, ± 1%, 1206 [3216公制]
1206 格式低电阻器 - 0.25W
ERJ 8R 芯片电阻器轻便紧凑。 这些芯片电阻器可提供高可靠性，由三层电极和金属上釉厚膜电阻元件制成。
符合 AEC-Q200
电流感应
小尺寸
低电阻值
适用于流动焊接和回流焊接
### 标准
IEC 60115-8, JIS C 5201-8, JEITA RC-2144
欧时:
Panasonic ERJ8RQ 系列 0.25W 2Ω 厚膜 低电阻SMD 电阻器 ERJ8RQF2R0V, ±1%, ±200ppm/°C, 1206 封装
立创商城:
2Ω ±1% 250mW
e络盟:
电流感应电阻器, 表面安装, 2 ohm, ERJ8R 系列, 1206 [3216公制], 250 mW, ± 1%, 厚膜
艾睿:
Use this ERJ-8RQF2R0V fixed single surface-mount resistor from Panasonic to obtain a visually clean layout. This product has a resistance value of 2 Ohm. This dependable part has a power rating of 0.25 1/4 W. It is also complete with current sensing technology. Its temperature coefficient is ±200 ppm/°C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 1%. This product is 3.2 mm long, 0.6 mm tall and 1.6 mm deep. This device is made with thick film technology. This part has an operating temperature of -55 to 125 °C.
Verical:
Res Thick Film 1206 2 Ohm 1% 1/4W ±200ppm/°C SMD Punched Carrier T/R
Newark:
SMD Current Sense Resistors, AEC-Q200 ERJ Series, 2 ohm, 250 mW, - 1%
