ERJ3BQF2R0V

PANASONIC ELECTRONIC COMPONENTS  ERJ3BQF2R0V  电流感应电阻器, 表面安装, AEC-Q200 ERJ系列, 2 ohm, 200 mW, ± 1%, 0603 [1608公制]

0603 格式 ERJ 3B 系列低电阻器 - 0.2W

ERJ 3B 厚膜芯片电阻器轻便紧凑。 这些电阻器由三层电极、金属釉厚膜电阻元件构成，非常可靠。

符合 AEC-Q200

电流感应

小尺寸

低电阻值

适用于流动焊接和回流焊接

### 标准

IEC 60115-8, JIS C 5201-8, JEITA RC-2144

欧时:
### 0603 格式 ERJ 3B 系列低电阻电阻器 - 0.2WPanasonic ERJ 3B 厚膜芯片电阻器轻便紧凑。 这些电阻器由三层电极、金属釉厚膜电阻元件构成，非常可靠。符合 AEC-Q200 电流感应 小尺寸 低电阻值 适用于流动焊接和回流焊接 ### 应用这些电流感应电阻器符合 AEC-Q200 标准，可在汽车应用中使用。 ### 标准IEC 60115-8, JIS C 5201-8, JEITA RC-2144### 厚膜 - 0402/0603

e络盟:
电流感应电阻器, 表面安装, 2 ohm, ERJ3B 系列, 0603 [1608公制], 330 mW, ± 1%, 厚膜

艾睿:
This is a ERJ3BQF2R0V fixed single surface-mount resistor from Panasonic. This part has a power rating of 0.25 1/4 W. This product has a resistance value of 2 Ohm. It is also complete with current sensing technology. Its temperature coefficient is ±200 ppm/°C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device is made with thick film technology. It has a tolerance of 1%. This part has an operating temperature of -55 to 125 °C. This product is 1.6 mm long, 0.45 mm tall and 0.8 mm deep.

Verical:
Res Thick Film 0603 2 Ohm 1% 0.25W1/4W ±200ppm/C Pad SMD Automotive T/R

Newark:
# PANASONIC ELECTRONIC COMPONENTS  ERJ3BQF2R0V  SMD Current Sense Resistors, AEC-Q200 ERJ Series, 2 ohm, 200 mW, - 1%
