ERJ3BQFR75V
数据手册.pdfPANASONIC ELECTRONIC COMPONENTS ERJ3BQFR75V 电流感应电阻器, 表面安装, AEC-Q200 ERJ系列, 0.75 ohm, 200 mW, ± 1%, 0603 [1608公制]
0603 格式 ERJ 3B 系列低电阻器 - 0.2W
ERJ 3B 厚膜芯片电阻器轻便紧凑。 这些电阻器由三层电极、金属釉厚膜电阻元件构成，非常可靠。
符合 AEC-Q200
电流感应
小尺寸
低电阻值
适用于流动焊接和回流焊接
### 标准
IEC 60115-8, JIS C 5201-8, JEITA RC-2144
欧时:
Panasonic ERJ3B 系列 0.2W 750mΩ 厚膜 低阻值SMD 电阻器 ERJ3BQFR75V, ±1%, ±300ppm/°C, 0603 封装
e络盟:
电流感应电阻器, 表面安装, 0.75 ohm, ERJ3B 系列, 0603 [1608公制], 330 mW, ± 1%, 厚膜
艾睿:
This is a ERJ-3BQFR75V fixed single surface-mount resistor from Panasonic. This part has a power rating of 0.25 1/4 W. This product has a resistance value of 750m Ohm. It is also complete with current sensing technology. Its temperature coefficient is ±300 ppm/°C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. It has a tolerance of 1%. This part has an operating temperature of -55 to 125 °C. This product is 1.6 mm long, 0.45 mm tall and 0.8 mm deep. This device utilizes thick film technology.
Verical:
Res Thick Film 0603 0.75 Ohm 1% 0.25W1/4W 0ppm/C to 300ppm/C Pad SMD Automotive T/R
Newark:
# PANASONIC ELECTRONIC COMPONENTS ERJ3BQFR75V SMD Current Sense Resistors, AEC-Q200 ERJ Series, 0.75 ohm, 200 mW, - 1%
