EL2480CSZ
数据手册.pdf为250MHz / 3毫安电流模式反馈放大器 250MHz/3mA Current Mode Feedback Amplifier
250MHz/3mA Current Mode Feedback Amplifier
The EL2480 is a quad current-feedback operational amplifier which achieves a -3dB bandwidthof 250MHz at a gain of +1 while consuming only 3mA of supply current per amplifier. It will operate with dual supplies ranging from ±1.5V to ±6V, or from single supplies ranging from +3V to +12V. In spite of its low supply current, the EL2480 can output 55mA while swinging to ±4V on ±5V supplies. These attributes make the EL2480 an excellent choice for low power and/or low voltage
cable-driver, HDSL, or RGB applications.
Features
• Quad topology
• 3mA supply current per amplifier
• 250MHz -3dB bandwidth
• Low cost
• Single- and dual-supply operation down to ±1.5V
• 0.05%/0.05° diff. gain/diff. phase into 150Ω
• 1200V/µs slew rate
• Large output drive current - 55mA
• Also available with disable in triple
• Pb-Free plus Anneal available RoHS compliant
Applications
• Low power/battery applications
• HDSL amplifiers
• Video amplifiers
• Cable drivers
• RGB amplifiers
• Test equipment amplifiers
• Current to voltage converters
