ECHU1C682GX5
数据手册.pdfPanasonic(松下)
被动器件
PANASONIC ELECTRONIC COMPONENTS ECHU1C682GX5 膜电容, ECHUX系列, 6800 pF, ± 2%, PPS聚亚苯基硫化物, 16 V, 0805 [2012公制]
值Capacitance| 0.0068uF \---|--- 容差Tolerance| ±2% AC额定电压Voltage Rating - AC| DC额定电压Voltage Rating - DC| 16V 介电材料Dielectric Material| PPS 等效串联电阻ESRESR Equivalent Series Resistance| Description & Applications| Features •Small in size minimum size 1.6 mm ✕ 0.8 mm •85 °C, 85 %RH, W.V. ✕ 1.0 for 500 hours •For reflow soldering •RoHS directive compliant Recommended Applications •Time-constant •Filtering •Oscillation and resonance 描述与应用| 特点 •体积小（最小尺寸1.6毫米✕0.8毫米） •85°C，相对湿度85％，W.V.- .
- 1.0 =500小时 •回流焊 •符合RoHS指令 推荐应用 •时间常数 •过滤 •振荡和谐振...............
