MAXIM INTEGRATED PRODUCTS DS1099U-FF+ 芯片, 定时器
The is a low frequency dual EconOscillator in 8 pin µMAX package. It is a low cost, low power, low frequency silicon oscillator that generates two square wave outputs with frequency of 32.750KHz. Individual output enables allow both outputs to be enabled/disabled independently. Both outputs are capable of sinking 16mA allowing them to directly interface to light emitting diodes LEDs as well as other external circuitry. The DS1099 operates over a wide supply voltage making it suitable for both 3V and 5V systems.
- .
- Supply voltage range is 2.7V to 5.5V
- .
- Operating temperature range from -40°C to 125°C
- .
- No external timing components required
- .
- Independent output enables OE0, OE1
- .
- CMOS/TTL compatible outputs
- .
- Relieves microprocessor of periodic interrupt
- .
- Low power consumption
- .
- Temp drift max is ±100ppm/°C
