CLM-120-02-F-D

SAMTEC CLM-120-02-F-D Board-To-Board Connector, 1mm, 40Contacts, Receptacle, CLM Series, Through Hole, 2Rows

40 位置 插座 0.039"（1.00mm） 表面贴装型 镀金

欧时:
1.00 mm Tiger Claw Rugged Reliable Dual

得捷:
CONN RCPT 40POS 0.039 GOLD SMD

立创商城:
1mm

艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this socket strip CLM-120-02-F-D header connector from Samtec on your PCB today! This SKT connector&s;s 40 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. Its pitch is 1 mm. It has a socket type gender. This is a 2-row connector. This device has a maximum current rating of 2.8 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 20.31 mm long, 2.26 mm tall and 3.81 mm deep. CLM-120-02-F-D is housed in black liquid crystal polymer.

安富利:
Conn Socket Strip SKT 40 POS 1mm Solder ST SMD Tube

Verical:
Conn Micro Socket Strip SKT 40 POS 1mm Solder ST SMD Tube

Newark:
# SAMTEC  CLM-120-02-F-D  Board-To-Board Connector, 1 mm, 40 Contacts, Receptacle, CLM Series, Through Hole, 2 Rows
