CLP-115-02-F-D
数据手册.pdfSamtec(申泰电子)
连接器
板至板连接, 1.27 mm, 30 触点, 插座, CLP Series, 表面安装 , 2 排
The CLP series from are Tiger Claw low profile rugged reliable dual wipe socket strips. These surface mount socket strips mates with Samtec FTSH, FTS and FW series of connectors.
- .
- Pitch spacing is 1.27mm 2 to 50 contacts per row with double row -D
- .
- High operating temperature range of -55°C to 125°C
- .
- Contact material is phosphor bronze
- .
- Black liquid crystal polymer insulator material
- .
- Voltage rating is 240VAC/340VDC
- .
- Complies with UL E111594 standard
- .
- Gold flash plated contacts
