CAY10-221J4LF
数据手册.pdf固定阵列电阻, 220 ohm, CAY10 Series, 4 元件, 隔离, 0804 [2010公制], 8 引脚
220 欧姆 ±5% 62.5mW 每元件功率 隔离 4 器网络，阵列 ±250ppm/°C 0804，凸面，长边端子
得捷:
RES ARRAY 4 RES 220 OHM 0804
立创商城:
220Ω ±5%
e络盟:
固定阵列电阻, 220 ohm, CAY10 Series, 4 元件, 隔离, 0804 [2010公制], 8 引脚
艾睿:
This CAY10-221J4LF resistor array by Bourns packs multiple resistors into one IC chip. This dependable part has a power rating of 0.25 1/4 W and a power rating per resistor of 0.063 1/16 W. This product&s;s 4 resistors have a value of 220 Ohm. Its temperature coefficient is ±250 ppm/°C. It has 8 terminals. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device is made with thick film technology. The CAY10-221J4LF part has a convex termination style. This product is 2 mm long, 0.35 mm tall and 1 mm deep. This part has an operating temperature of -55 to 125 °C. It has a tolerance of 5%. This product&s;s terminal pitch is 0.5 mm.
Chip1Stop:
Res Thick Film Array 220 Ohm 5% 0.25W1/4W ±250ppm/℃ ISOL Molded 8-Pin 08044 X 0402 Convex SMD T/R
Verical:
Res Thick Film Array 220 Ohm 5% 0.25W1/4W ±250ppm/C ISOL 8-Pin 08044 X 0402 Convex SMD T/R
Electro Sonic:
Res Thick Film Array 220 Ohm 5% 0.25W1/4W ±250ppm/°C ISOL 8-Pin 08044 X 0402 Convex SMD T/R
