CW160808-33NJ
数据手册.pdf高Q值的片式电感器 High Q Chip Inductors
High Q Chip Inductors
Features
■0603 size
■ Available in E12 series
■ High Q - up to 80 typ.
■ High operating temperature of 125 °C
■ Small size of only 1.6 mm
■RoHS compliant- .
Applications
■Mobile phones
■Cellular phones
■ CTV, VCR, HIC, FDD
立创商城:
33nH ±5% 220mΩ
得捷:
FIXED IND 33NH 600MA 220MOHM SMD
艾睿:
This chip CW160808-33NJ surface mount inductor from Bourns is ideal for saving valuable space on a PCB. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This product is 1.85 mm long, 1.2 mm tall and 1.25 mm deep. This device is made with wirewound technology. This SMD inductor has a maximum DC current of 600m A with a maximum resistance of 220m Ohm. It has a tolerance of 5%. Its test frequency is 250M Hz, while its minimum self-resonant frequency is 2.3G Hz. It has an inductance of 33n H.
安富利:
Ind Chip Wirewound 33nH 5% 250MHz 35Q-Factor Alumina 600mA 0603 T/R
Verical:
Inductor Chip Wirewound 33nH 5% 250MHz 35Q-Factor Alumina 600mA 220mOhm DCR 0603 T/R
Newark:
# BOURNS CW160808-33NJ Surface Mount High Frequency Inductor, CW160808 Series, 33 nH, 600 mA, 0603 [1608 Metric]
MASTER:
Inductor RF Wirewound 0.033uH 5% 250MHz 35Q-Factor Alumina 0.6A 0.22Ohm DCR 0603 T/R
Electro Sonic:
Inductor RF Wirewound 0.033uH 5% 250MHz 35Q-Factor Alumina 0.6A 0.22Ohm DCR 0603 T/R
Win Source:
FIXED IND 33NH 600MA 220MOHM SMD / 33 nH Unshielded Drum Core, Wirewound Inductor 600 mA 220mOhm 0603 1608 Metric
