B2B-EH-ALFSN

JST JAPAN SOLDERLESS TERMINALS  B2B-EH-ALFSN  线至板连接器, EH系列, 2 触点, 针座, 2.5 mm, 压配合, 1 排

EH 系列直向管座

EH 系列 2.5mm 节距单排有罩顶部接入（直向）印刷电路板管座。它们具有一体式键接结构，确保在配接时正确定位。有关对应的压接插座外壳，请参见 RS 311-6209（典型）；有关 IDC 插座外壳，请参见 RS 311-6287（典型）。

### 注

制造商部件号为 BxxB-EH-A 的产品具有 3.2mm 长的引脚，部件号 BxxB-EH 的产品具有 4.0mm 长的引脚。

### 认可

UL 文件号 60389，CSA 文件号 LR20812

得捷:
CONN HEADER VERT 2POS 2.5MM

欧时:
JST PCB 针座 EH 系列 2路 2.5mm节距 1排 直向 B2B-EH-A LF SN, 焊接端接, 3A, 通孔

立创商城:
EH 2.5mm 1x2P

e络盟:
线至板连接器, 2.5 mm, 2 触点, 针座, EH系列, 压配合, 1 排

艾睿:
JST Corporation brings you their shrouded B2B-EH-A LFSN header connector, an important safety tool for protecting your electronic components from accidental damage. This HDR connector&s;s 2 contacts that are made out of brass and plated with tin over copper. This is a 1-row connector. Its pitch is 2.5 mm. It has a straight body orientation. It has a maximum voltage rating of 250 VDC|250VAC. It has a header type gender. This device has a maximum current rating of 3 A. This product is 7.5 mm long, 6 mm tall and 3.8 mm deep. It uses the solder termination method. This connector has an operating temperature of -25 to 85 °C. B2B-EH-A LFSN is housed in white nylon 6/6.

Verical:
Conn Shrouded Header 3 Sides HDR 2 POS 2.5mm Solder ST Top Entry Thru-Hole Box

Newark:
# JST JAPAN SOLDERLESS TERMINALS  B2B-EH-ALFSN  Wire-To-Board Connector, EH Series, Press Fit, Header, 2, 2.5 mm, Tin Plated Contacts

Win Source:
CONN HEADER EH TOP 2POS 2.5MM

CDI:
ShroudedHeader, Top Entry, 2Circuit, 2.5mmPitch
