BBS-109-G-A

2.54mm 圆针

针座 通孔 9 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 9POS 2.54MM

立创商城:
2.54mm 圆针

艾睿:
Mounting this unshrouded BBS-109-G-A header connector from Samtec to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 9 contacts that are made out of phosphor bronze|brass and plated with gold over nickel. It has a header type gender. This is a 1-row connector. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. BBS-109-G-A is housed in black polyester. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 22.86 mm long, 8.51 mm tall and 2.54 mm deep.

Newark:
# SAMTEC  BBS-109-G-A  Board-To-Board Connector, 2.54 mm, 9 Contacts, Header, BBS Series, Solder, 1 Rows
