BBS-104-G-A

SAMTEC  BBS-104-G-A  板至板连接, BBS系列, 4 触点, 针座, 2.54 mm, 通孔安装, 1 排

Connector Header Through Hole 4 position 0.100" 2.54mm

得捷:
CONN HEADER VERT 4POS 2.54MM

e络盟:
板至板连接, 2.54 mm, 4 触点, 针座, BBS系列, 通孔安装, 1 排

艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this unshrouded BBS-104-G-A header connector from Samtec. This HDR connector&s;s 4 contacts that are made out of phosphor bronze|brass and plated with gold over nickel. Its pitch is 2.54 mm. This is a 1-row connector. It has a header type gender. It has a straight body orientation. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 10.16 mm long, 8.51 mm tall and 2.54 mm deep. It uses the solder termination method. BBS-104-G-A is housed in black polyester. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST Thru-Hole Tube

Chip1Stop:
Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST Thru-Hole Tube

Newark:
# SAMTEC  BBS-104-G-A  Board-To-Board Connector, BBS Series, Through Hole, Header, 4, 2.54 mm, Gold Plated Contacts
