AC164127

Expansion board with LCD display; PICtail Plus; Interface: PMP

The is a Graphics PICtail™ Plus daughter board 2. It is a demonstration board for evaluating graphic LCD display solution and graphics library for 16bit and 32bit microcontrollers. It is an expansion board compatible with the explorer 16 development board. To get started, an explorer 16 development board is required. The Graphics PICtail Plus daughter board 2 should be inserted into expansion connector, J9, of the explorer 16 board. The graphics PICtail Plus daughter board 2 can be configured with several jumpers. The Graphics PICtail Plus daughter board 2 can be used in conjunction with the graphics library for microcontrollers.

.

QVGA 320x240 LCD module with built in graphics controller and resistive touch screen

.

Stand alone graphics controller, solomon systech SSD1906

.

4Mbit 512Kx8 flash memory for additional data storage

.

Featured with sound buzzer
