67997-220HLF

Use this unshrouded 67997-220HLF header connector from FCI where IDC ribbon cables are used. This HDR connector&s;s 20 contacts that are made out of phosphor bronze and plated with gold over nickel|gxt over nickel. It has a header type gender. This is a 2-row connector. Its pitch is 2.54 mm. It has a maximum voltage rating of 1500 VAC. It has a straight body orientation. This device has a maximum current rating of 3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -65 to 125 °C. This product is 25.4 mm long, 8.38 mm tall and 4.83 mm deep. It uses the solder termination method. 67997-220HLF is housed in black nylon|polychlorinated terphenyl|liquid crystal polymer.

Connector Header Through Hole 20 position 0.100" 2.54mm

得捷:
CONN HEADER VERT 20POS 2.54MM

艾睿:
BergStik®, Board to Board connector, Unshrouded vertical header, Through Hole, Double Row, 20 Positions, 2.54 mm 0.100in Pitch
