TSW-113-15-F-D

SAMTEC TSW-113-15F-D Board-To-Board Connector, 2.54mm, 26Contacts, Header, TSW Series, Through Hole, 2Rows

针座 位置

得捷:
CONN HDR T/H .025" SQUARE P

艾睿:
Thanks to Samtec&s;s unshrouded TSW-113-15-F-D header connector, you can reduce the possibility of accidentally shorting out any pins on your printed circuit. This HDR connector&s;s 26 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. This is a 2-row connector. It has a header type gender. Its pitch is 2.54 mm. It has a maximum voltage rating of 550 VAC. This device has a maximum current rating of 6.3 A/contact. This product is 33.02 mm long, 15.75 mm tall and 5.08 mm deep. It uses the solder termination method. TSW-113-15-F-D is housed in black polyester. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 26 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-113-15-F-D  Board-To-Board Connector, 2.54 mm, 26 Contacts, Header, TSW Series, Through Hole, 2 Rows
