QMS-026-09.75-SL-D-A

板至板连接, 0.635 mm, 52 触点, 针座, QMS Series, 表面安装　, 2 排

The is a 52-position 2-row single-ended rugged Ground Plane Header with gold-plated phosphor bronze contacts and a liquid crystal polymer insulator.

.

-55 to +125°C Operating temperature range

得捷:
CONN HDR 52POS SMD GOLD

欧时:
0.635 mm Q2 High-Speed Rugged Ground Pl

立创商城:
QMS-026-09.75-SL-D-A

e络盟:
板至板连接, 0.635 mm, 52 触点, 针座, QMS Series, 表面安装　, 2 排

艾睿:
Think of Samtec&s;s micro high speed terminal strip QMS-026-09.75-SL-D-A header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This HDR connector&s;s 52 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 0.635 mm. It has a maximum voltage rating of 300 VAC. It has a straight body orientation. It has a header type gender. This is a 2-row connector. This device has a maximum current rating of 2.6/15.7 A/contact. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. QMS-026-09.75-SL-D-A is housed in black liquid crystal polymer. This product is 20.83 mm long, 9.72 mm tall and 7.52 mm deep.

Verical:
Conn Micro High Speed Terminal Strip HDR 52 POS 0.635mm Solder ST SMD Tray

Newark:
# SAMTEC  QMS-026-09.75-SL-D-A  Board-To-Board Connector, 0.635 mm, 52 Contacts, Header, QMS Series, Solder, 2 Rows
