HTSW-106-07-L-D

SAMTEC HTSW-106-07-L-D Board-To-Board Connector, 2.54mm, 12Contacts, Header, HTSW Series, Through Hole, 2Rows

针座 通孔 12 位置 0.100"（2.54mm）

欧时:
High Temperature PCB HDR Strips 0.100"

得捷:
CONN HEADER 12POS .100" T/H GLD

艾睿:
Reduce safety concerns with this unshrouded HTSW-106-07-L-D header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector&s;s 12 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a maximum voltage rating of 550 VAC. It has a header type gender. This is a 2-row connector. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. HTSW-106-07-L-D is housed in natural liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C. This product is 15.24 mm long, 8.38 mm tall and 5.02 mm deep. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 12 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  HTSW-106-07-L-D  Board-To-Board Connector, 2.54 mm, 12 Contacts, Header, HTSW Series, Through Hole, 2 Rows
