87215-4

AMPMODU 14 位置 双排 2.54 mm 间距 垂直 针座 - 通孔

Standard Header Type, Thermoplastic Housing, 0.025 in. Post Size, Through Hole Header

** Housing** : Black thermoplastic, 94V-0 rated. ** Posts** : Copper alloy.

0.125 " termination post length

得捷:
CONN HEADER VERT 14POS 2.54MM

贸泽:
集管和线壳 UNSHRD VERT DUAL 14

艾睿:
As an added safety precaution, the unshrouded 87215-4 header connector from TE Connectivity will prevent and protect components on your circuit board from accidentally touching each other. This HDR connector&s;s 14 contacts that are made out of copper alloy and plated with gold over nickel. It has a straight body orientation. It has a header type gender. Its pitch is 2.54 mm. This is a 2-row connector. This device has a maximum current rating of 3 A/contact. It uses the solder termination method. This connector has an operating temperature of -65 to 105 °C. This product is 17.37 mm long, 10.37 mm tall and 5.08 mm deep. 87215-4 is housed in black thermoplastic.

Allied Electronics:
MODU THRU DRHDR UNSHR, 14 MODII HDR DRST UNSHRD .100

安富利:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Thru-Hole

Chip1Stop:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Thru-Hole Carton

Verical:
Conn Unshrouded Header M 14 POS 2.54mm Solder ST Top Entry Thru-Hole Carton

Newark:
# AMP - TE CONNECTIVITY  87215-4  Board-To-Board Connector, AMPMODU Mod II Series, 14 Contacts, Header, 2.54 mm, Through Hole, 2 Rows

MASTER:
ASSEMBLY, MOD II, HEADER, DOUBLE ROW, .100 X .100 CL. VERTICAL, .025 SQUARE POSTS

Powell:
.100 inch AMPMODU Headers

Online Components:
14 MODII HDR DRST UNSHRD .100

Electro Sonic:
14 MODII HDR DRST UNSHRD .100
