826629-5
数据手册.pdfAMP FROM TE CONNECTIVITY 826629-5 板至板连接, AMPMODU MOD II系列, 5 触点, 针座, 2.54 mm, 通孔安装, 1 排
AMPMODU Mod II 2.54 mm 单排无罩分离式引脚管座
AMPMODU Mod II 无罩单排分离式印刷电路板引脚管座，具有 2.54mm 中心线。这些多用途 AMPMODU Mod II 分离式印刷电路板管座可拆分成所需尺寸。一次性安装所有焊接柱，节省时间和人力成本。这些 2.54mm AMPMODU Mod II 引脚管座提供垂直或直角安装方向。还提供表面安装型号
### 特点和优势
多用途，可分拆为所需尺寸
安装起来快速且省时
可靠且实惠
### 应用
这些 AMPMODU Mod II 印刷电路板引脚管座适用于各种应用。应用包括汽车控制、工业和测试设备、计算机、通信、医疗仪器、存储设备和电器
得捷:
CONN HEADER VERT 5POS 2.54MM
欧时:
TE Connectivity 引脚管座 AMPMODU Mod II 系列 5路 2.54mm节距 1排 直向 826629-5, 焊接端接, 3A, 通孔
立创商城:
826629-5
贸泽:
集管和线壳 5P SINGLE ROW
e络盟:
板至板连接, 2.54 mm, 5 触点, 针座, AMPMODU MOD II系列, 通孔安装, 1 排
艾睿:
This unshrouded 826629-5 header connector from TE Connectivity reduces the possibility of accidentally shorting pins when a board is being used. This HDR connector&s;s 5 contacts that are made out of brass and plated with gold over nickel. It has a header type gender. This is a 1-row connector. Its pitch is 2.54 mm. It has a straight body orientation. This device has a maximum current rating of 3 A/contact. 826629-5 is housed in green polybutylene terephthalate. This connector has an operating temperature of -65 to 105 °C. This product is 12.7 mm long, 9.5 mm tall and 2.5 mm deep. It uses the solder termination method.
Allied Electronics:
5w Single row straight header gold
安富利:
Conn Unshrouded Header HDR 5 POS 2.54mm Solder ST Thru-Hole
Chip1Stop:
Conn Unshrouded Header HDR 5 POS 2.54mm Solder ST Thru-Hole
Verical:
Conn Unshrouded Header HDR 5 POS 2.54mm Solder ST Top Entry Thru-Hole Carton
Newark:
# AMP - TE CONNECTIVITY 826629-5 Board-To-Board Connector, AMPMODU MOD II Series, Through Hole, Header, 5, 2.54 mm
MASTER:
AMPMODU II PIN HEADER, SINGLE ROW, DUAL ROW, VERTICAL AND RIGHT ANGLE MOUNT
Powell:
.100 inch AMPMODU Headers
Online Components:
AMPMODU II HEADER
Electro Sonic:
AMPMODU II HEADER
