7B41-01-2

隔离，电压或电流输入 Isolated, Voltage or Current Input

Product Details

The 7B41 is a new addition to our highly acclaimed 7B Series of Process Control Signal Conditioners. The 7B41 accepts mV/Volt inputs up to +/-50V as standard ranges, the standard outputs are 1-5V or 0 to +10V . The 7B41 is a wide bandwidth conditioner with standard bandwidth of 10KHz. Filtering on the 7B41 is a 7 pole Butterworth function.

### Features and Benefits

.

Accepts Volt Inputs

.

General Purpose Isolation

.

10 KHz BW

.

1-5V or 0-10V Output
