796866-5

可插拔接线端子 5 POS HDR RT ANGLE

5 针位端子块 接头，公引脚，带罩（4 面） 0.200"（5.08mm） 90°，直角 - 通孔

得捷:
TERM BLOCK HDR 5POS 90DEG 5.08MM

贸泽:
可插拔接线端子 5 POS HDR RT ANGLE

艾睿:
Think of TE Connectivity&s;s shrouded 796866-5 header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This HDR connector&s;s 5 contacts that are made out of phosphor bronze and plated with tin. Its pitch is 5.08 mm. This is a 1-row connector. It has a right angle body orientation. It has a header type gender. It has a maximum voltage rating of 300 VAC. This device has a maximum current rating of 15 A/contact. This product is 35.48 mm long, 8.35 mm tall and 12 mm deep. 796866-5 is housed in green polyamide 6/6. It uses the solder termination method.

安富利:
Conn Shrouded Header HDR 5 POS 5.08mm Solder RA Thru-Hole

Verical:
Conn Shrouded Header 4 Sides M 5 POS 5.08mm Solder RA Side Entry Thru-Hole Carton

MASTER:
TERMINAL BLOCK HEADER ASSEMBLY, 90 DEGREE, WITH FLANGE, 5.08mm PITCH

Powell:
Terminal Block Connectors

Online Components:
5 POS TERMI-BLOK HDR RT ANGLE

Electro Sonic:
5 POS TERMI-BLOK HDR RT ANGLE
