796867-4
数据手册.pdf可插拔接线端子 4 POS HDR VERTICAL
4 POS TERMI-BLOK HDR VERTICAL
Product Highlights
Connector
Connector Type = Header
Shrouded
Housing Color = Green
Not Side Stackable
得捷:
TERM BLOCK HDR 4POS VERT 5.08MM
贸泽:
可插拔接线端子 4 POS HDR VERTICAL
艾睿:
Think of TE Connectivity&s;s shrouded 796867-4 header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This HDR connector&s;s 4 contacts that are made out of phosphor bronze and plated with tin. It has a straight body orientation. It has a header type gender. It has a maximum voltage rating of 300 VAC. Its pitch is 5.08 mm. This is a 1-row connector. This device has a maximum current rating of 15 A/contact. It uses the solder termination method. 796867-4 is housed in green polyamide 6/6. This product is 30.4 mm long, 12 mm tall and 8.35 mm deep.
Verical:
Conn Shrouded Header 4 Sides M 4 POS 5.08mm Solder ST Top Entry Thru-Hole Carton
Newark:
# AMP - TE CONNECTIVITY 796867-4 4 POS TERMI-BLOK HDR VERTICAL New
MASTER:
TERMINAL BLOCK HEADER ASSEMBLY, VERTICAL, WITH LOCKING SCREW
Powell:
Terminal Block Connectors
Online Components:
4 POS TERMI-BLOK HDR VERTICAL
Electro Sonic:
4 POS TERMI-BLOK HDR VERTICAL
