3-338169-2
数据手册.pdf15 位置 2 排 通孔 直角 公头 引脚 D-Sub
AMPLIMITE HDP-20系列高密度, 带有压接式触芯. 该连接器设计用于后部插入和拔出, 20尺寸, 精密触芯. 该连接器具有钢制外壳与黑色聚合物插入件, 带有塑料接触固定齿. 可选择多种尺寸以满足生产需求, 适应各种安装和硬件要求. 该连接器采用梯形连接面配置, 具有多个极化和连接对齐功能, 可确保系统设计灵活性. 插头连接器具有一体式罩, 可保护插入的插针触芯. 为了易于识别, 腔行采用数字编码. 该连接器可接受线缆尺寸为28至18AWG触芯.
得捷:
CONN D-SUB PLUG 15POS R/A SLDR
欧时:
15P HDP20 PLUG ASSY
立创商城:
3-338169-2
e络盟:
D-Sub 连接器, 插头, AMPLIMITE HDP-20 Series, 15 触点, DB, 焊接
艾睿:
Be sure to set up proper communication between your serial connections with the 3-338169-2 DVI connector from TE Connectivity. It has a right angle body orientation. Its pitch is 2.74 mm. This 2-row connector has a single port. This device has a maximum current rating of 6 A/contact. 3-338169-2 is housed in polyester. This component will be shipped in tray format. This DVI connector has an operating temperature of -55 to 105 °C. Its 15 terminals use the solder termination method. This product is 39.2 mm long, 13.6 mm tall and 21.3 mm deep.
安富利:
Conn D-Subminiature PIN 15 POS 2.74mm Solder RA Thru-Hole 15 Terminal 1 Port
Chip1Stop:
Conn D-Subminiature PIN 15 POS 2.74mm Solder RA Thru-Hole 15 Terminal 1 Port Tray
Verical:
Conn D-Subminiature PIN 15 POS 1.37mm Solder RA Thru-Hole 15 Terminal 1 Port Tray
Newark:
D Sub Connector, Amplimite HDP-20, Amplimite HDP-20 Series, DB, Plug, 15, Metal, Solder
MASTER:
HD-20 SIZE 2 RIGHT ANGLE PLUG HEADER; MARK II+
Powell:
Standard Board Mount Connectors
Electro Sonic:
15P HDP20 PLUG ASSY
