3006P-1-203LF

BOURNS  3006P-1-203LF  微调器,15转 20K

19mm in. 750mW 矩形端部调节 3006 系列标准型

Bourns 标准 3006P 系列 19mm in. 矩形端部调节陶瓷微调电容器，额定功率 @ 70°C 750mW。3006P 系列金属陶瓷微调电容器转动臂转到终端就会停转且封闭式设计，可进行电路板冲洗。

额定 15 转调整角度

提供面板安装适配器，库存号 107-6878

欧时:
Bourns 3006 系列 15 转 通孔 微调电阻器 3006P-1-203LF, 带针接端, 20kΩ ±10%, 0.75W, ±100ppm/°C

得捷:
TRIMMER 20KOHM 0.75W PC PIN SIDE

立创商城:
20kΩ ±10%

贸泽:
Trimmer Resistors - Through Hole 20K 3/4" 10% Sealed Multi Turn

艾睿:
Res Cermet Trimmer 20K Ohm 10% 0.75W3/4W 15ElecTurn 2.36mm 20.57 X 4.83 X 6.35mm Pin Thru-Hole Tube

Allied Electronics:
Trimmer; Cermet; Rest 20 Kilohms; PCB; Pwr-Rtg 0.75W; Dim 0.75InLx0.19InWx0.25InH

Jameco:
Resistor Cermet Trimmer 20K Ohm 10% 0.75W 3/4W 15ElectricalTurn 2.36mm 20.57 X 4.83 X 6.35mm Pin Thru-Hole

安富利:
Res Cermet Trimmer 20K Ohm 10% 3/4W 15ElecTurn 2.36mm 20.57 X 4.83 X 6.35mm Pin Thru-Hole Tube

Chip1Stop:
Res Cermet Trimmer 20K Ohm 10% 0.75W3/4W 15ElecTurn 2.36mm 20.57 X 4.83 X 6.35mm Pin Thru-Hole Tube

TME:
Potentiometer: mounting; multiturn; 20kΩ; 750mW; ±10%; linear

Verical:
Res Cermet Trimmer 20K Ohm 10% 0.75W3/4W 15ElecTurn 2.36mm 20.57 X 4.83 X 6.35mm Pin Thru-Hole Tube

Newark:
# BOURNS  3006P-1-203LF  Trimmer, Multiturn, 20 kohm, 750 mW, ± 10%, Trimpot 3006 Series, 15 Turns, Through Hole

MASTER:
Trimmer Potentiometer - 20K Ohm - 0.75W3/4W - 15ElecTurn - 20.57 X 4.83 X 6.35mm - Pin - Through Hole.

Electro Sonic:
Trimmer Potentiometer - 20K Ohm - 0.75W3/4W - 15ElecTurn - 20.57 X 4.83 X 6.35mm - Pin - Through Hole.

Win Source:
TRIMMER 20K OHM 0.75W PC PIN
