PIC16C74A-20/L
数据手册.pdfMicrochip(微芯)
微处理器
MICROCHIP PIC16C74A-20/L 微控制器, 8位, 一次性可编程, PIC16C7xx, 10 MHz, 7 KB, 192 Byte, 44 引脚, LCC
The is a PIC16 family 8-bit powerful 200 nanosecond instruction execution yet easy-to-program only 35 single word instructions CMOS one-time programmable OTP based Microcontroller packs powerful PIC®RISC architecture. This product offer all of the advantages of the well recognized mid-range x14 architecture with standardized features including 7kB of addressable program memory size, 192bytes of data memory size, 33 general-purpose I/O pins and 8-channel 8-bit analog-to-digital A/D converter. This device operates at a maximum frequency of 20MHz with wide operating voltage of 2.5 to 5.5V.
- .
- 35 14-bit wide easy instructions to learn
- .
- 8 level hardware stack
- .
- Interrupt capability
- .
- Power-on reset POR
- .
- Power-up timer PWRT
- .
- Oscillator start-up timer OST
- .
- Watch dog timer WDT
- .
- Two 8-bit digital timers
- .
- Programmable code-protection
- .
- Power saving SLEEP mode
- .
- Brown-out reset BOR
- .
- One 16-bit digital timers
- .
- 2x Capture/Compare/PWM CCP
- .
- Parallel slave port
