LTC2321IUFD-16#PBF
数据手册.pdfLINEAR TECHNOLOGY LTC2321IUFD-16#PBF 模数转换器, 双路, 16 bit, 2 MSPS, 单, 4.75 V, 5.25 V, QFN
The is a low noise, high speed dual differential input successive approximation register Analog-to-digital Converter ADC with differential inputs and wide input common mode range. It has an 8VP-P differential input range, making it ideal for applications which require a wide dynamic range with high common-mode rejection. The ADC achieves ±4LSB INL typical, no missing codes at 16-bit and 81dB SNR. It has an on-board low drift 2.048/4.096V temperature-compensated reference. The ADC also has a high speed SPI-compatible serial interface that supports CMOS or LVDS. The fast 2Msps per channel throughput with no cycle latency makes the ADC ideally suited for a wide variety of high speed applications. The ADC dissipates only 31mW per channel and offers nap and sleep modes to reduce the power consumption to 5µW for further power savings during inactive periods.
- .
- Guaranteed 16-bit, no missing codes
- .
- 8VP-P Differential inputs with wide input common mode range
- .
- No cycle latency
- .
- CMOS or LVDS SPI-compatible serial I/O
- .
- Power dissipation 31mW/Ch
