207441-9

集管和线壳 PIN HEADER ASSY 9P

METRIMATE PIN HEADER ASSY,9P

Product Highlights

Connector

Connector Type = Header

Square Grid Connector Configuration

9 Positions

Pin

得捷:
CONN HEADER VERT 9POS 5MM

贸泽:
集管和线壳 PIN HEADER ASSY 9P

艾睿:
Connecting an electronic device to a power supply has never been easier with this 207441-9 power connector from TE Connectivity. This PIN connector&s;s 9 contacts that are made out of brass and plated with gold over nickel. It has a maximum voltage rating of 600 VAC. This connector has a single port. It has a straight body orientation. Its pitch is 5 mm. 207441-9 is housed in nylon. This device has a maximum current rating of 14 A/contact. The item will be shipped in tray orientation. Its 9 terminals use the solder termination method. This product is 27.69 mm long, 11.79 mm tall and 27.69 mm deep. This power connector has an operating temperature range of -55 °C to 130 °C.

安富利:
Conn Power PIN 9 POS 5mm Solder ST Thru-Hole 9 Terminal 1 Port

Verical:
Conn Rectangular PIN 9 POS 5mm Solder ST Thru-Hole 9 Terminal 1 Port Tray

Powell:
Metrimate Connectors

Online Components:
METRIMATE PIN HEADER ASSY,9P

Electro Sonic:
METRIMATE PIN HEADER ASSY,9P
