2-640445-2
数据手册.pdfConn Unshrouded Header HDR 22POS 3.96mm Solder ST Thru-Hole
22P MTA156 HDR ASSY FL/STR SN
Product Highlights
MTA-156 Connectors
Number of Positions = 22
Mating Type = Header
Wire-to-Board Application
3.96 mm Contact Centerline Spacing
得捷:
CONN HEADER VERT 22POS 3.96MM
艾睿:
Use this unshrouded 2-640445-2 header connector from TE Connectivity where IDC ribbon cables are used. This HDR connector&s;s 22 contacts that are made out of copper alloy and plated with tin. It has a straight body orientation. It has a maximum voltage rating of 600 VAC. Its pitch is 3.96 mm. It has a header type gender. This is a 1-row connector. This device has a maximum current rating of 7 A/contact. It uses the solder termination method. 2-640445-2 is housed in white polyester. This connector has an operating temperature of -55 to 105 °C. This product is 87.17 mm long, 13.33 mm tall and 7.62 mm deep.
Chip1Stop:
Conn Unshrouded Header HDR 22 POS 3.96mm Solder ST Thru-Hole
Verical:
Conn Unshrouded Header HDR 22 POS 3.96mm Solder ST Thru-Hole Package
Newark:
# AMP - TE CONNECTIVITY 2-640445-2 22P MTA156 HDR ASSY FL/STR SN
MASTER:
MTA-156 HEADER ASSEMBLY, FRICTION LOCK, STRAIGHT .045 SQUARE POST, TIN PLATED
Online Components:
22P MTA156 HDR ASSY FL/STR SN
Electro Sonic:
22P MTA156 HDR ASSY FL/STR SN
