207444-8

TE Connectivity Metrimate 5mm 方形栅格引脚和插座印刷电路板管座Metrimate 方形栅格引脚和插座印刷电路板安装管座，具有红色热塑性 94V-0 等级外壳和 5mm 中心线。 这些方形栅格引脚和插座印刷电路板安装管座预装了铜合金、镀锡或镀金双工引脚触点或磷青铜、镀锡或镀金双工插座触点，并具有锁定插片和安装耳。### TE Connectivity Metrimate 系列5mm 节距连接器 适合面板或自由安装 比 Mate-N-Lok 系列引脚更高

Metrimate 5mm 方形栅格引脚和插座印刷电路板管座

Metrimate 方形栅格引脚和插座印刷电路板安装管座，具有红色热塑性 94V-0 等级外壳和 5mm 中心线。 这些方形栅格引脚和插座印刷电路板安装管座预装了铜合金、镀锡或镀金双工引脚触点或磷青铜、镀锡或镀金双工插座触点，并具有锁定插片和安装耳。

得捷:
CONN HEADER VERT 18POS 5MM

欧时:
### TE Connectivity Metrimate 5mm 方形栅格引脚和插座印刷电路板管座Metrimate 方形栅格引脚和插座印刷电路板安装管座，具有红色热塑性 94V-0 等级外壳和 5mm 中心线。 这些方形栅格引脚和插座印刷电路板安装管座预装了铜合金、镀锡或镀金双工引脚触点或磷青铜、镀锡或镀金双工插座触点，并具有锁定插片和安装耳。### TE Connectivity Metrimate 系列5mm 节距连接器 适合面板或自由安装 比 Mate-N-Lok 系列引脚更高

艾睿:
Do you need to connect a power supply to a circuit? Then this 207444-8 power connector from TE Connectivity is perfect for you! This PIN connector&s;s 18 contacts that are made out of copper alloy and plated with gold over nickel. This connector has a single port. It has a maximum voltage rating of 600 VDC|600VAC. It has a straight body orientation. Its pitch is 5 mm. 207444-8 is housed in nylon. This device has a maximum current rating of 14 A/contact. The item will be shipped in tray orientation. Its 18 terminals use the solder termination method. This power connector has a minimum operating temperature of -55 °C and a maximum of 130 °C. This product is 47.32 mm long, 11.79 mm tall and 24.23 mm deep.

Allied Electronics:
Metrimate Series, 5mm Pitch 18 Way 3 RowStraight PCB Header, Solder Term, 14A

Jameco:
Connector Power Pin 18 Position 5mm Solder Straight Through Hole 18 Terminal 1 Port

安富利:
Conn Power PIN 18 POS 5mm Solder ST Thru-Hole 18 Terminal 1 Port

Chip1Stop:
Conn Power PIN 18 POS 5mm Solder ST Thru-Hole 18 Terminal 1 Port

Verical:
Conn Rectangular PIN 18 POS 5mm Solder ST Thru-Hole Tray

Newark:
# AMP - TE CONNECTIVITY  207444-8  METRIMATE PIN HEADER ASSY,18P

Powell:
Metrimate Connectors

Online Components:
METRIMATE PIN HEADER ASSY,18P

ICbanQ:
Rectangular Connectors 18P PIN HEADER GOLD METRIMATE

Electro Sonic:
METRIMATE PIN HEADER ASSY,18P
