2-1445053-6

管脚和插座连接器 HDR VERT 6 POS TIN SINGLE ROW

Connector Header Surface Mount 6 position 0.118" 3.00mm

得捷:
CONN HEADER SMD 6POS 3MM

贸泽:
管脚和插座连接器 HDR VERT 6 POS TIN SINGLE ROW

艾睿:
This specially engineered 2-1445053-6 power connector from TE Connectivity is designed for various high voltage and current supplies. This HDR connector&s;s 6 contacts that are made out of brass and plated with tin over nickel. It has a straight body orientation. It has a maximum voltage rating of 250 VAC. It has a header type gender. Its pitch is 3 mm. This connector has a single port. 2-1445053-6 is housed in nylon. This device has a maximum current rating of 5 A/contact. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This product is 5.67 mm deep. Its 6 terminals use the solder termination method. This power connector has an operating temperature range of -40 °C to 105 °C.

安富利:
Conn Power HDR 6 POS 3mm Solder ST SMD 6 Terminal 1 Port

MASTER:
Conn Power HDR 6 POS 3mm Solder ST SMD 6 Terminal 1 Port Tape

Powell:
3mm Centerline, 250V, 5 A max.
